Weights
01 Operating Weight
19.080 kgs
Attachments
02 Arm
Standard
03 Bucket
3.5 M3 Cutting Edge
Traction
04 Tires
23.5R25 L3 TRI
Drive
05 Transmission
Full Powershift
Engine
06 Model
Develon DL08
07 Fuel
Diesel
08 Cooling
Liquid
09 Number of cylinders
6
10 Rated horse power
172 kW - 2000 rpm
11 Maximum Torque
118 kgf.m @ 1300 rpm
12 Emission
Tier3
Hydraulic System
13 Max flow
140/140/56 l/min
Loading Cycles Time
14 Lifting speed (loaded)
5.9 sec
15 Dumping speed (loaded)
1.7 sec
16 Lowering speed (empty)
3.0 sec
Fluids Capacity
17 Fuel Tank
291 liter
18 Cooling Liquid
44 liter
19 Engine Oil
35 liter
20 Hydraulic Oil
193 liter
21 Gear Box & Torque Converter
42 liter
22 Front Axle
35 liter
23 Rear Axle
35 liter
Standard Features
2 Spool Control Valve
Air Conditioner
Radio + MP3 (Stereo)
Rotating Beacon
Rear View Camera
Quick coupler provision only
Suspension Seat
ROPS
Telematics (TMS cell only)
Tools
